FACE GROOVING27OALDCONMSCDXaCW OHNDAXNCDXCWOHNDimensions Recommended Machining DataDesignation DAXN(1) CW CDX DCONMS OHN(2) OAL a IC908f face-groove(IPR)PICJ RF10D6T1.5-10 .24 .039 .059 .236 .43 1.024 .205 %u2022 .0004-.0016PICJ RF15D6T2.0-10 .24 .059 .079 .236 .43 1.024 .205 %u2022 .0004-.0016PICJ LF15D8T2.5-20 .31 .059 .098 .276 .83 1.378 .232 %u2022 .0004-.0016PICJ RF10D8T1.5-10-6 .31 .039 .059 .236 .43 1.024 .205 %u2022 .0004-.0016PICJ RF10D8T1.5-20-7 .31 .039 .059 .276 .83 1.378 .232 %u2022 .0004-.0016PICJ RF10D8T1.5-30-7 .31 .039 .059 .276 1.18 1.772 .232 %u2022 .0004-.0016PICJ RF15D8T2.5-10-6 .31 .059 .098 .236 .43 1.024 .205 %u2022 .0004-.0016PICJ RF15D8T2.5-20-6 .31 .059 .098 .236 .79 1.378 .205 %u2022 .0004-.0016PICJ RF15D8T2.5-30-7 .31 .059 .098 .276 1.18 1.772 .232 %u2022 .0004-.0016PICJ RF20D8T3.0-10-6 .31 .079 .118 .276 .43 1.024 .232 %u2022 .0008-.0020PICJ RF20D8T3.0-20-6 .31 .079 .118 .236 .79 1.378 .205 %u2022 .0008-.0020PICJ R/LF20D8T3.0-30-7 .31 .079 .118 .276 1.18 1.772 .232 %u2022 .0008-.0020PICJ RF25D8T3.5-10-6 .31 .098 .138 .276 .43 1.024 .232 %u2022 .0008-.0020PICJ RF25D8T3.5-20-7 .31 .098 .138 .276 .83 1.378 .232 %u2022 .0008-.0020PICJ RF30D8T3.5-10-6 .31 .118 .138 .276 .43 1.024 .232 %u2022 .0008-.0024PICJ RF30D8T3.5-20-6 .31 .118 .138 .276 .83 1.378 .232 %u2022 .0008-.0024PICJ RF30D8T3.5-30-7 .31 .118 .138 .276 1.18 1.772 .232 %u2022 .0008-.0024%u2022 Only right-hand inserts are available as standard %u2022 All inserts are with sharp corners %u2022 PICJ items are suitable for PICCO/MG PCO, PICCO ACE, SC-PICCO types holders only(1) Minimum axial grooving diameter (2) Minimum overhang PICJ R/LF-D6/8-T (Face Grooving)Inserts with Internal Coolant Channel for Face Grooving
